TECHNICAL DETAILS

.

CARRIAGE (mm)
E F G
1070 1000 1220
1320 1300 1520
1600 1800 1720

LOG_CARRIAGES_UTA

  • Hydraulic feeding speed up to 85 m/min with steel rope drive system. Hydrostatic feeding system with the speeds with up to 120, 160, 200 m/min (Option)
  • Speed of head blocks is up to 200 mm/sec. provided by AC driven(up to 320, 500 mm/sec. Option)
  • two sets of joysticks with six button each to control head blocks, hooks and turning arms and 1 set of hydraulic pedal for carriage forward backward movement (Option)

.

.

FEATURES

.

  • Comfortable, easy to use, operator friendly remote control
  • Manufactured from 200 mm I-beams. Heavy and strong mainframe
  • Independent horizontal hooks movement for easier positioning of logs
  • Fixed fence-horizontol movable hooks. The distance between fence and hooks can be adjusted to desired position min: 35 mm- max: 145 mm
  • In the advanced controlled log carriages, by the help of independent horizontal move hooks, log is able to be easily aligned according to cut axis while clamped and is able to be adjusted to a fix distance of the hook and the fence –min:15mm – max:145mm (Option)
  • Hydraulic system centrifugal turning arms. Turning arms inclination up to 90°
  • Chains of turning devices are driven by reducer
  • Log holding steel bars that protect the headblock guides getting damage by log and make the log to be turned easily
  • Electronic thickness gauging system manufactured and designed by ÜSTÜNKARLI, has the possibility of remaining and outgoing thickness gauging, 8 memories and entering values directly, 50 programs for different diameter of width, optimization between 50 programs, possibility of instant programing manually and 5 different groups between 50 programs
  • Automatic central lubrication
